| Configuration | ||
|---|---|---|
| Connector type | SMA plug/male | |
| Cable series (size) | SC-358/50 series (outer diameter size 3.58mm) | |
| Body type | Straight | |
| Cable attachment method | Solder | |
| Electrical properties | ||
|---|---|---|
| Frequency range | DC to 18GHz | |
| Characteristic impedance | 50ohms | |
| Insulation resistance @DC500V | Minimum 10,000 megohms | |
| Dielectric withstanding voltage @sea level | 1,000Vrms | |
| Mechanical properties | ||
|---|---|---|
| Body material and plating | Gold-plated stainless steel | |
| Coupling nut material and plating | Gold-plated stainless steel | |
| Gasket | Silicon | |
| Retaining ring | Beryllium copper | |
